Flexo printer slotter（detail）

Flexo printer slotter

Fl exo printer slotter has wide applications in various field.This type of flexo printer slotter inherits all the merits of the original model, enhanced by new technology. Compared with other flexo printer slotter, our flexo printer slotter enjoys many advantages including: more reasonable structure, more compact appearance, smoother operating, higher efficiency and is easy to operate and maintain. flexo printer slotter has wide adoptablity, is an ideal flexo printer slotter for you to convert into production. flexo printer slotter that you need is just what we can supply. We are one of the most famous flexo printer slotter exporters in China. We have been supplying a whole set of flexo printer slotter for overseas customers. We would like to provide maximun customer satisfaction at lowest possible cost and best after-sale service. If you need flexo printer slotter, please feel free to contact us.

we are leading company of exporting cardboard making machines and Flexo Printer slotter in China. Our Flexo printer slotter have been sold to many customers both in home and abroad. Our Flexo Printer Slotter has won good reputation in overseas market. Our Flexo printer Slottor is welcomed by its competitive price and reliable quality. We will supply comprehensive aftersales services.

696 model of high-speed four-color Flexo printer slotter

· Paper Feeding Unit: Adopting vacuum adsorption automatic scraping paper feeding system. Elastic rubber roller feeding ensures No harmful for corrugation intensity. Dust remover(upper) system .It can clean up dust on the surface of cardboard Continuous paper feeding .Pneumatic locking system. .Side baffle and back baffle position are regulated by electric device.

Main technical parameter Item Unit Contents Model 696 2800 Model feeding paper area mm2 2700×1600 effective printing area mm2 2500×1600 Min.process size mm2 600×420 Thickness range of cardboard mm 1.5-16mm  Max.speed sheets/min 120 Economic speed sheets/min 80 Motor  power kw 28 Weight T 28 Printing precision mm ±0.75 Slotting precision mm ±1.5

·Printing Unit:

Standard configuration: metal net stripe roller with 220 meshes.(180, 200meshes is for option)
Phase and left-right movement of printing mould are regulated automatically.which can be displayed on screen directly.it can be regulated by touchable screen or by buttons.
Dividing position fix device.ensures each printing mould relative position keep unchanged.
electric drive dividing part,Pneumatic lock.
Printing roller adopts both adhesive printing and hanging printing.



Slotting Unit :

Phase and left-right movement of slotting disc are regulated by Digital controller. Which can be regulated and displayed on the touchable screen directly. It can be regulated by by buttons too. The right-left movemrnt of slotting disc can be regulated correlatively. The up slotting disc set and up scorering wheel can be regulated correlatively. The regulation size can be read from rulermark directly.

Dividing position fixing device.ensures each unit relative position keep unchanged when it is separate and close.
Opening slot place is adjusted by united electricity power.

Main parts of drive adopts no bond connection collapsible.

Machine Set

Paper feeding unit, Printing Unit, Slotting Unit all adopts automatic spray lubrication system. It adopts double oil pump balance system.

Automatic Stack Unit :
Automatic counting system. Rise and fall of stack arm is controlled by pneumatic. Stack arm rise and fall is regulated automatically according to cardboard feeding quantity. The motor is speed regulation motor.

Computer Control System
Main control system adopts touchable screen. Operation is easy and direct
Return-to-zero and memory erase function. Each part phase return-to-zero and preset and horizontal position return-to-zero. It ensures error can be compensated automaticlly in process of printing, die-cutting and solotting if there is error in first cardboard.
Main motor is VVVF motor. Operation stable. Power saving.
Prefeed. The unique prefeed function increases printing speed greatly.
Paper feed and printing process orderly. Enhances printing quality(including the last paper) greatly.
Die cutting serve move and hydraulic pneumatic move.
Slotting disc up disc and up scorer wheel horizontal move relatively regulation.
Parameters correction. Basic parameters correction. Makes maintainence and regulation easy.
Slotting disc Protection device.
Multi-points control system.
PLC control system. Each unit relative phase, horizontal movement, flute depth, carton height can be controlled and displayed.

Die Cutting Unit: ( it can be assembled to the printer slotter)

Phase and left-right movement of die mould is regulated by Digital controller. Which can be regulated and displayed on the touchable screen directly. The die mould phase can be regulated by buttons too.

Dividing position fixing device.ensures each unit relative position keep unchanged when separate and close.

Electric drive dividing part, Pneumatic lock..
Die cutting rubber roller adopts serve movement and hydraulic pneumatic horizontal movement system. It also is equiped with rubber cushion self-repair system. The rubber cushion can be self-prepair many times. After repairing, the diameter of rubber roller is input computer system. Which makes cumpter calculate and follow printing speed. It ensures cardboard die cutting more neatly. At the same time, it keep die cutter from being harmed.
Main parts of drive adopts no bond connection collapsible.



Machine Set

Paper feeding unit, Printing Unit, Slotting Unit all adopts automatic spray lubrication system. It adopts double oil pump balance system.

Automatic Stack Unit :
Automatic counting system. Rise and fall of stack arm is controlled by pneumatic. Stack arm rise and fall is regulated automatically according to cardboard feeding quantity. The motor is speed regulation motor.

Computer Control System
Main control system adopts touchable screen. Operation is easy and direct
Return-to-zero and memory erase function. Each part phase return-to-zero and preset and horizontal position return-to-zero. It ensures error can be compensated automaticlly in process of printing, die-cutting and solotting if there is error in first cardboard.
Main motor is VVVF motor. Operation stable. Power saving.
Prefeed. The unique prefeed function increases printing speed greatly.
Paper feed and printing process orderly. Enhances printing quality(including the last paper) greatly.
Die cutting serve move and hydraulic pneumatic move.
Slotting disc up disc and up scorer wheel horizontal move relatively regulation.
Parameters correction. Basic parameters correction. Makes maintainence and regulation easy.
Slotting disc Protection device.
Multi-points control system.
PLC control system. Each unit relative phase, horizontal movement, flute depth, carton height can be controlled and displayed.

Die Cutting Unit: ( it can be assembled to the printer slotter)

Phase and left-right movement of die mould is regulated by Digital controller. Which can be regulated and displayed on the touchable screen directly. The die mould phase can be regulated by buttons too.

Dividing position fixing device.ensures each unit relative position keep unchanged when separate and close.

Electric drive dividing part, Pneumatic lock..
Die cutting rubber roller adopts serve movement and hydraulic pneumatic horizontal movement system. It also is equiped with rubber cushion self-repair system. The rubber cushion can be self-prepair many times. After repairing, the diameter of rubber roller is input computer system. Which makes cumpter calculate and follow printing speed. It ensures cardboard die cutting more neatly. At the same time, it keep die cutter from being harmed.
Main parts of drive adopts no bond connection collapsible.



YK902 series of high-speed four-color Flexo Printer Slotter

·Paper Feeding  Unit: Vacuum absorption, automatic  paper feeding with patent technology of  rotation scraping knife. Paper feeding adopts rubber roller.which is no  harmful for corrugated intensity. Dust cleaning device: used to clean dust on the surface of cardboard.

Main technical parameter Item Unit Contents Model YK902 φ330 × 1700 φ330 × 1900 φ330 × 2100 φ500 × 2100 φ500 × 2300 φ500 × 2600 φ500 × 2700 Feeding paper area mm2 1000×1750 1000×1950 1000×2150 1500×2200 1500×2400 1500×2700 1500×2800 Effective printing area mm2 1000×1700 1000×1900 1000×2100 1500×2050 1500×2250 1500×2550 1500×2650 Min.process size mm2 550×250 550×250 550×250 550×400 550×400 550×400 550×400 Thickness of cardboard mm 4-9 Max.speed Sheets/min 120 120 120 100 100 100 100 Economic speed Sheets/min 80 80 80 70 70 70 70 Printing precision mm double color ±0.5,three color ±0.75,four color ±1

·Printing Unit:
Standard configuration: metal net stripe roller with 165 meshes.(180, 200meshes is for option)
Phase and left-right movement of printing mould are regulated by electrical device. which can be displayed on dial.
Dividing position fix device.ensures each printing mould relative position keep unchanged.
electric drive dividing part,Pneumatic lock.
Printing roller adopts both adhesive printing and hanging printing.

printing roller regulation range in horizontal direction:  +/-8mm

·Slotting Unit:
Three group of slotting. one group of corner cutting. two group of paper dividing . Four group of scoring. punching machine is an option.
Phase adjusting are made by electrical device. which can be read on dial..
Dividing position fix device.ensures each printing mould relative position keep unchanged.
Electrical dividing device .pneumatic lock . slotting part is adjusted relatively. slotting knife and cardboard height  are regulated relatively.

·The main machine:
printing unit and slotting unit  adopts oil-soaking lubrication system. which starts to lube when turn on the machine.

YK901-B series three-color Flexo Printer Slotter

·Paper Feeding Unit: Digital accounting of number. hand-feeding paper side check plate position fixing. ·Printing Unit: Standard configuration: metal net stripe roller with 165 meshes.(180 meshes is for option) Phase and left-right movement of printing mould are regulated by manual. which can be displayed on dial. printing roller regulation range in horizontal direction:  +/-8mm

Main technical parameter Item Unit Contents Model YK901-B2100 YK901-B2300 YK901-B2600 YK901-B2700 Max.thickness of feeding paper  mm 13.5 13.5 13.5 13.5 Paper feeding area mm2 1500×2250 1500×2450 1500×2750 1500×2850 Effective printing area mm2 1500×2100 1500×2300 1500×2600 1500×2700 Min.process size mm2 600×400 600×400 600×400 600×400 Thickness of plank mm 4-9 Max.speed Sheets/min 60 60 60 60 Economic speed Sheets/min 0-50 0-50 0-50 0-50 Printing precision mm double color ＋0.5 three color ＋0.75 four color ＋1 Motor power kw 5.5 5.5 5.5 5.5

·Slotting Unit:
Three group of slotting. one group of corner cutting. two group of paper dividing . Four group of scoring. punching machine is an option.
Fast Phase adjusting are made by manual. which can be read on dial..
Dividing position fix device.ensures each printing mould relative position keep unchanged.
Electrical dividing device .pneumatic lock . slotting part is adjusted relatively. slotting knife and cardboard height  are regulated relatively.

·The Main Machine:

printing unit and slotting unit  adopts oil-soaking lubrication system. which starts to lube when turn on the machine.

Automatic Slotting & Corner-cutting Machine

Mechanical specifications major parameter unit RS-7 Max. cardboard size mm 2500×1400 Feeding in alternate sheets 2500×1800 Min. cardboard size mm 650×350 Min. slotting size mm 240×60×240×60 slotting width mm 7 Suitable cardboard thickness mm 1.5-11 Max. production speed sheet/min. 100 dimension mm 3700×2950×1350 Weight kg About 5400 Gross power (main engine) hp 13 　 Note: It is subject to change without notice.

FYQKY 1800-2600 Multi-function type machine

Name Unit 1800 2000 2200 2400 2600 Max. paper feed size mm 1800×1500 2000×1500 2200×1500 2400×1500 2600×1550 Max. printing area mm2 1540×1500 1740×1500 1940×1500 2140×1500 2340×1500 Minimum carton size mm 350×600 350×600 350×600 350×600 350×600 Max. printing thickness mm 350 350 350 350 350 Max. speed pcs/min 80 80 80 80 80 Motor power kw 3 3 3 3 3 Weight T 3.6 3.9 4.2 4.5 4.8 Contour dimension mm 4590×2240×1550 4590×2440×1550 4590×2640×1550 4590×2840×1550 4590×3040×1550

Three-function slotting machine with a straight-through chain

Name Unit 2000 2200 2400 2600 2750 max. paper feed size mm 1950×1500 2150×1500 2350×1500 2550×1500 2750×1795 min. cardboard size processed mm 1740×1500 1940×1500 350×600 350×600 400×600 min. slotting range mm 150 150 150 150 150 max. speed pcs/min 80 80 80 80 60 motor power kw 1.1 1.1 1.5 1.5 3 weight T 1.5 1.6 1.7 1.8 3.0

Print the slotting machine in automatic high-speed swimming skill

	Feeding Unit ■ A vac-sorb system is used in it. Feeding period is synchronized with plate cylinder. Feeding is normal for thin cardboard and bending cardboard, too. ■Both of the left guard and the right one can be adjusted broadwise by a motor. ■The feeding height for the front guard can be adjusted manually. ■The rear guard can be adjusted vertically by a brake motor. ■The strength of cardboard will not be damaged even if the feeding gap is small, because of the adaptation of a spring buffer device on the feeding roller.
	Slotting Unit ■ The slotting cutter can be adjusted circumferentially at 360°by a motor during its rotation. ■Both of the top slotting cutter and the bottom slotting cutter can be synchronously adjusted broadwise by hand, and the adjusted position will be shown on the dividing ruler. ■ The cutter shaft is sturdy and durable because it is electroplated with hard chromium and abraded precisely.
	Up stacker ■ Max stacking height：1600mm ■ Max sheet length acceptable：3000mm ■ Lift-lower of stacking deck operated by motor. ■ Width：1400mm ,1600mm ,1800mm
	Printing Unit ■ The printing roller can be adjusted circumferentially at 360°during its rotation. ■The plate cylinder can be adjusted manually axially by hand during its rotation. ■ The checker roller is a metal roller or a ceramic roller which are engraved by laser, and can be separated from the surface of the press plate automatically. ■There is a fast plate-hanging device on the plate cylinder so as to load and unload the press plate quickly.

After saling flexo printer slotter, if necessary, We will send one or two engineers to set up and commissioning of the  flexo printer slotter until it running in normal state. Druing the time your workers who will operate the flexo printer slotter will be trained.
The pioneers in exporting flexo printer slotter in China.
